Waveshare 0.96 Inch OLED Display (B)


  1. Driver Chip: SSD1306
  2. Interface: 3-wire SPI, 4-wire SPI, I2C
  3. Resolution: 128 x 64
  4. Display Size: 0.96 inch
  5. Applicability: Hardware platforms such as Raspberry Pi/Jetson Nano/Arduino/STM32
SKU: RK009780 Categories: , ,


This is a Waveshare 0.96 Inch OLED Display (B) module. It is a very high-contrast display with no backlight.  It is perfect when you need an ultra-small display. This module supports SPI/I2C communication interfaces. It supports various hardware platforms such as Raspberry Pi/Jetson Nano/Arduino/STM32.

Comparing to LCD, OLED screens are way more competitive, which has a number of advantages such as high brightness, self-emission, high contrast ratio, slim outline, wide viewing angle, wide temperature range, and low power consumption. This module provides 3 kinds of driver interfaces; they are 3-wire SPI, 4-wire SPI, and I2C interface.

Pin Definition:

1.GND: Power ground
2.VCC: Power positive
3.SCL: Serial Clock Line
4.SDA: Serial Data wire.


  1. Better quality
  2. The IIC address can be changed, it is convenient to use with different machines.
  3. Four square holes are easy to install

Package Includes:

1 x 0.96 Inch OLED Display (B)
